WALL AIRCOND
ACSON A3WM15S
Split System Air Conditioner A3WM 15N
Key Features
- Nominal Cooling Capacity: 12000 BTU/h (3.52 kW)
- Nominal Total Input Power: 1040 W
- Nominal Running Current: 4.61 A
- CSPF: 3.59
- Power Supply: 220-240V / 1 / 50
- WiFi Control (Optional)
- LCD Remote Control / WiFi Control (Optional)
- Automatic Louver (Up & Down)
- Air Discharge: Turbo (176 l/s / 372 CFM)
- Sound Pressure Level (SPL): 40/39/35/29/28 dBA
- Condensate Drain Size: 19.05 mm (0.75 in)
- Unit Weight: 14 kg (30.86 lb)
- Pipe Connection: 6.35 (1/4) Liquid, 9.52 (3/8) Gas
- Maximum Piping Length: 25 m
- Maximum Piping Height: 15 m
- Refrigerant Type: R32
RM 1498.00
RM 1840.00
- 19%
In Stock. Ready to be shipped!
Features
Model Indoor
A3WM 15N
Model Outdoor
A3LC 15F
MEPS Star Rating
4 Star (Image shown)
Control
WiFi Control (Optional)
Operation
LCD Remote Control / WiFi Control (Optional)
Air Discharge
Automatic Louver (Up & Down)
Specifications
| Nominal Cooling Capacity | 12000 BTU/h / 3.52 kW |
|---|---|
| Nominal Total Input Power | 1040 W |
| Nominal Running Current | 4.61 A |
| CSPF | 3.59 |
| Power Supply | 220-240V / 1 / 50 |
| Indoor Unit Height | 310 mm (12.20 in) |
| Indoor Unit Width | 1065 mm (41.93 in) |
| Indoor Unit Depth | 224 mm (8.80 in) |
| Indoor Unit Packaging Height | 386 mm (15.20 in) |
| Indoor Unit Packaging Width | 1136 mm (44.72 in) |
| Indoor Unit Packaging Depth | 314 mm (12.36 in) |
| Outdoor Unit Air Flow | 438 l/s (927 CFM) |
| Outdoor Unit Sound Pressure Level (SPL) | 48 dBA |
| Outdoor Unit Height | 550 mm (21.65 in) |
| Outdoor Unit Width | 658 mm (26.00 in) |
| Outdoor Unit Depth | 273 mm (10.75 in) |
| Outdoor Unit Packaging Height | 610 mm (24.02 in) |
| Outdoor Unit Packaging Width | 781 mm (30.75 in) |
| Outdoor Unit Packaging Depth | 363 mm (14.29 in) |
| Outdoor Unit Weight | 28 kg (61.73 lb) |
| Fin Spec | Bare Aluminium Fin or Hydrophilic Gold Fin |
| Pipe Connection Type | Flare Valve |
| Pipe Connection Liquid Size | 6.35 mm (1/4 in) |
| Pipe Connection Gas Size | 9.52 mm (3/8 in) |
